2 TWIN SCREW COMPRESSORS Today in thousands of application worldwide, Howden oil injected screw compressors are regularly applied to provide high integrity, low maintenance solutions for liquid chilling, direct refrigeration and gas compression applications. Howden not only introduced the concept of the operational twin screw compressor to the world market more than 50 years ago, but have been instrumental in the development of the oil injected twin screw compressor concept, which has revolutionised world designs of refrigeration and gas handling plants. COMPRESSION CYCLE (Diagrammatic only) The international installed base of Howden Compressors in a wide and varied range of applications is unparalleled.
- Howden Wrv 204 Manual Transfers
- Howden Wrv 204 Manual Transfer Case
- Howden Wrv 204 Manual Transfer Video
DESIGN CONCEPT Compression is achieved by the intermeshing of two helical rotors contained in a suitable casing. Figures 1-4 give details of the compression cycle. Fig 1 Gas is drawn in to fill the interlobe space between adjacent lobes.
The Howden twin screw compressor is a positive displacement rotary design. As such, Howden compressors have the characteristics and stability of reciprocating compressors by offer particular advantages of: Reduced Physical Size Low Vibration Reduced Moving Parts Extended Operating Life Cycle CONSTRUCTION All Howden twin screw compressors have paired rotors, machined from solid bar or forgings which involves a high degree of complexity and accuracy.
Fig 2 As the rotors mesh, the gas is trapped between the rotors and the casing. Normally casings will be cast iron, machined to close tolerance levels. However, to match particular gas requirements, high discharge pressure applications, or applicable international standards and codes, alternative casing construction in spheroidal graphite iron or various grades of steel will be offered when appropriate. Alternative designs of compressors from the Howden product range are available as required. 3 DEVELOPMENT AND TESTING DESIGN Howden twin screw compressors are designed to match the exacting specifications required by our customers and comply with International Standards and Codes. Howden ensure that their compressors go beyond the normal operating technical performance parameters required to give customers wide margins in terms of operational capability and efficiency. Compressors are generally Lloyds approved and installations have been accepted by many major authorities, such as Lloyds, Bureau Veritas, Norske Veritas, RINA, DSRK, Bureau de Mines, Germanischer Lloyd and NKK.
DEVELOPMENT Howden s technology lead has been maintained over many years by total commitment to continuous product development. Market requirements are continuously reviewed, in order that the Development Department can not only monitor ever changing operating conditions, but ensure that production capability will always reflect current or anticipated system demands worldwide.
In particular, Howden is totally committed to ensure that products meet current or future demands for environmental protection, in terms of CFC free refrigerants, secure captivity of hazardous gases, and the best possible energy efficiency. All Howden Compressors products are capable of operation on CFC free refrigerants, with the fullest possible attention being given to energy conservation. In the development of our new XRV range of compressors, for example, both full capacity and volume ratio control are available. TEST At Howden Compressors, test is considered to be a vital function, both in terms of product development and to ensure specification compliance.
All new products are comprehensively tested, to ensure that design is fully optimised and performance data provided by the company, particularly in the form of computer selection programs for standard gases and refrigerants, is as accurate as possible. In addition, all compressors are hydrostatically tested to a minimum of 1.5 times maximum working pressure, and are also subjected to mechanical run function test on one of Howden s air test rigs, to ensure that volumetric efficiency, mechanical function, and vibration fall within stringent acceptance standards.
QUALITY CONTROL Howden Compressors recognise the importance of a controlled manufacturing environment, where design, development, procurement, production and test are controlled in such a way as to ensure the highest possible standards of production and performance, demanded by Howden and their customers, are consistently achieved. To this end, the company operates to the requirements of ISO 9001 (BS5750-Part 1, EN 29001) and has been accredited by Lloyds Register Quality Assurance as complying with this standard. Ongoing internal and external audits of quality control systems are applied to ensure continued compliance with necessary control procedures.
Howden Wrv 204 Manual Transfers
Quality Plans can also be prepared to match project requirements, where we are required to manufacture to specific customer requirements, which may apply in particular applications. 4 MANUFACTURING & CUSTOMER SUPPORT ROTORS All Howden twin screw rotors are machined from solid bar or forgings. Standard material is carbon steel, but for more arduous applications, special alloys or stainless steels are utilised.
Rotors are machined on specialist machining centres, to the exacting tolerances necessary to ensure the highest possible operating efficiency. CNC rotor machining centre in operation. A feature of Howden rotors is that sealing strips are machined on the crown of the male rotor lobes, and matching grooves are incorporated in the root of the female rotor to maximise the gas seal. Following machining and balancing to ISO standards, male and female rotors are paired for assembly to ensure the ideal combination for maximum efficiency. Completion of the manufacturing process in the rotor machining centre.
Precision machining of a WRV compressor casing. CASINGS Casings are precision machined from castings, which will normally be graphite cast iron, but may be nodular iron, carbon steels, or stainless steel, depending on the application. As with the twin screw rotors, precision machining of compression path components is critical, to ensure that Howden standards are maintained in terms of operational efficiency. Components such as the main casing and inlet and outlet end covers are flanged, bolted and dowelled through flanges to ensure correct alignment.
Howden Wrv 204 Manual Transfer Case
Removal of the end covers provides ready access for maintenance when required. Finished machined compressor casing.
Assembly of a large WRV compressor. COMPRESSOR ASSEMBLY All oil injected twin screw compressors are assembled in the Glasgow production facility by skilled engineers, who ensure that Howden quality control requirements, which conform with ISO 9001, are strictly maintained. During the manufacturing process, all casing components are subjected to hydraulic test, to a minimum of 1.5 times maximum operating pressure, to ensure integrity.
Additionally, all oil injected compressors are tested with air under water following final assembly. Compressors are then mechanically run, to confirm that volumetric efficiency, absorbed power, oil flows and vibration are to Howden acceptance standards. Final inspection of a WRV 510 compressor prior to shipment. Assembly of WRV oil injected compressors. PRODUCT SUPPORT SPARE PARTS AND RE-BUILD CAPACITY In partnership with its global alliance of gas and refrigeration package manufacturers and distributors, Howden offers a fast and efficient parts supply service. Parts are generally pre-packaged in kits which, in addition to being readily available from Howden facilities in the UK and the USA, will normally be available from locally based Howden compressor package distributors.
Following many years operation, a full service re-build of the compressor may be appropriate. A full re-build and re-test capability is offered by Howden in both their UK and USA service shops. A full warranty, equivalent to new product warranty, is available to Howden customers following a full compressor re-build. Original Howden Spares Kits 4. 5 OIL INJECTED COMPRESSORS Howden oil injected twin screw compressors are used for liquid chilling, direct refrigeration, and for hydrocarbon gas applications involving hydrocarbons, fuel gas, or other specialist applications. In some instances, hydrocarbon gases such as propane, butane or propylene, will be used as an industrial refrigerant.
TYPICAL APPLICATIONS Industrial Refrigeration Fuel Gas Compression Liquid Chillers Food Processing Marine Air Conditioning & Refrigeration Breweries Mine Cooling Hydrocarbon Processing Gas Liquefaction Petrochemical and Chemical Processing Natural Gas Gathering Carbon Dioxide Recovery Coke Oven Gas UNIQUE FEATURES AND BENEFITS OF OIL INJECTED DESIGN SUPERFEED Slide Valve Capacity Control Capacity and energy absorbed match system demand. The Howden Superfeed system is a development of the oil injected screw compressor design. All oil injected compressors are equipped with an additional gas port, located along the length of the compression chamber.
Feeding refrigerant to this port from a superfeed/economiser vessel within the refrigeration system offers increased evaporator capacity of up to 20 percent, with virtually no increase in absorbed power. Variable Volume Ratio Liquid Refrigerant Injection Maximises energy efficiency. Reduces capital cost with minimal reduction in operating efficiency. GAS HANDLING Typical gases or refrigerants handled by the Howden range of oil injected screw compressors include: Refrigerants Gases NH3 Ammonia Methane R12/R134a Butane Natural Gas R22/KLEA 66/AZ5000 Coke Oven Gas Nitrogen R502/R404A/R407A/ Fuel Gas Propane AZ 50 Helium Propylene Propane Hydrocarbon Sour Gas Butane (Wet & Mixed) Town Gas Propylene Hydrogen OIL INJECTED COMPRESSOR RANGE Howden offer a range of capability which is unparalleled N.B: In some cases, for example in refineries, hydrocarbon gases will be used as refrigerants. 6 WRV COMPRESSORS WRV compressors represent the bench mark against which industry comparison is made for both gas and refrigeration applications. Features and benefits of WRV compressors include: Plain-Shell Type Journal Bearings Double Wall Construction Optional Material of Construction Long operational life span Suitable for high pressure application Flexibility to match project specification (e.g.
API 619) Oil Injected Seal/ Bearing Construction Range of Capability Installed Compressors High quality gas seal from simple construction Probably the most comprehensive range of capacity available More than 20,000 WRV compressors installed worldwide All WRV range compressors are of double wall construction and utilise white metal, sleeve type journal bearings with pressurised shaft seal. A full range of Vi options from 2.1 to 5.8 is offered for each compressor while slide valve capacity control is a standard feature on all compressors. Many options to standard design are available, some of which are indicated below: C Conditioning version with reduced oil flow for dense gases such as R22 M Mirror version for reverse rotation with double ended motor drive and two stage design. H Higher pressure version for high discharge pressure.
X extra high discharge design. T Tilting pad thrust bearing design, e.g. To comply with API 619. S Steel casings for high pressure or to match specification. N Nodular cast iron design again for specific project specification. 7 XRV COMPRESSORS XRV compressors have been developed specially for the refrigeration market.
Features and benefits of XRV compressors include: Ease of Installation Use of Roller Bearings Variable Vi Ideal for horizontal separator applications No oil pump for over 90% of installations Available with either adjustable or fully automatic Vi system Stepless Capacity Control Combined with variable Vi, gives maximum energy saving Ease of Service Separate end covers give easy access to rolling elements VARIABLE VOLUME RATIO Two forms of variable volume control are available. ADJUSTABLE VOLUME RATIO (MVi) 2. AUTOMATIC VARIABLE VOLUME RATIO (AVi) As is known, care is taken during compressor selection to ensure that the correct volume ratio is selected by comparison to the chosen operating conditions. However, in many instances the compressor is selected against peak conditions which may only apply for a very few days each year. While it is essential to select hardware which is capable of operating in the most extreme environment, it does not follow that the compressor will necessarily always perform at the highest possible efficiency. The Howden variable Vi concept, coupled to slide valve capacity control, offers alternative methods of controlling capacity and volume ratio to suit site conditions. Where the pressure ratio across the compressor is consistently high or changes in pressure ratio are infrequent (e.g.
The change from winter to summer conditions) then the MVi manually adjustable system will be entirely satisfactory. With lower pressure ratios, or where condensing conditions vary frequently, the Howden automatic control AVi system is ideal. 10 XRV TECHNICAL DATA TYPICAL PERFORMANCE AMMONIA TYPICAL PERFORMANCE R22 EVAPORATION TEMPERATURE EVAPORATION TEMPERATURE EVAPORATING TEMPERATURE EVAPORATING TEMPERATURE KEY TO GRAPHS Full Duty 50 Hz (Excluding Superfeed ) Condensing Temperature 95 F (35 C) Full Duty 60Hz (Excluding Superfeed ) Condensing Temperature 95 F (35 C) NOTES Refrigeration capacity based on 5.6 C (10 F) superheat at compressor suction and no sub-cooling of condensed liquid No allowance has been made for pressure losses between the evaporator and the compressor suction flange 10.
When you think about emergency power options for your home or business, a probably comes to mind. This provides electricity independently from the grid when the power goes out.All wired-in generators require a transfer switch to begin delivering electricity to your lights, appliances and electronics. You have two main transfer switch options: an automatic transfer switch and a manual transfer switch. Which one you choose depends on your electrical demands, your budget and what type of business you operate. Purpose of a Transfer SwitchThe transfer switch is responsible for trading your home or business’s energy supply from the utility company to the backup generator.
It isolates the generator from municipal power lines to protect utility repairmen from power surges caused by backfeeding. This essential piece of safety equipment is required with all wired-in backup generator installations in all 50 states. How Does a Manual Transfer Switch Work?When the power goes out, everything will go dark if you have a manual transfer switch. You’ll need to grab your flashlight and go out to the generator to start it manually and connect it to the transfer switch. Then you’ll need to switch your home or business over to receive power from the generator. When utility power comes back on, you need to manually switch the power back to the utility company and turn off the generator. How Does an Automatic Transfer Switch Work?As the name implies, everything is automatic with this type of transfer switch.
The power may go out for a second or two, but the transfer switch senses this and automatically signals your generator to start up. Then the transfer switch connects your home or business to the generator. When utility power comes back on, the transfer switch disconnects the power supply from the generator and shuts the generator back off until the next power outage occurs. Which Transfer Switch is Right for Me?The primary advantage of a manual transfer switch is the lower cost to design, fabricate and install it.
It’s also smaller in size, faster to fabricate, and easier to install and maintain than an automatic transfer switch.The extra investment required to install and maintain an automatic transfer switch may be worth it if you live in an area prone to regular power outages. A lack of power interruption is also necessary for some types of businesses, including hospitals and data centers, where losing power could have serious, even life-threatening consequences. The Importance of Professional InstallationElectricity is dangerous, and any electrical-related installation should be handled by a licensed electrician. The National Electrical Code requires transfer switches to meet certain safety standards, which you can only confidently achieve with professional installation.Plus, electricians know how to properly size transfer switches to match the power capacity of a backup generator. This is important to prevent the system from overloading when the power generator kicks on, something that could damage the very appliances and electronics you’re hoping to use while utility services are down.The professionals at Mr. Electric® know how to safely and accurately wire your generator into your home or business’s service panel.
We can teach you how to use a manual transfer switch if you choose this option, or we can set up an automatic transfer switch to do all the work for you.Keep productivity and electricity flowing – install a backup generator today. Contact to learn more about meeting your emergency power needs. Whether for home or business, our community of fellow home service brands at can help ensure you're back on your feet regardless of the emergency you face.
